Anterior Cervical Plating System is indicated for cervical trauma, cervical degenerative diseases, spinal tumors, cervical deformities and pseudarthrosis, and it is also applicable for combined anterior-posterior cervical spine surgery to provide stable fixation and facilitate bony fusion.
Center line alignment groove design.
Large bone graft window design.
Pre-curved steel plate,in line with the physiological curve of cervical spine.
Low-cut edge design.
Self-tapping screws reduce the use of taps.
Distinguish screws by color,quickly distinguish diameter and type.
Fixed Angle Bone screws and Variable .
Angle Bone Screws are used together for different indications.
| Anterior Cervical Plate | Fixed Angle Bone Screw （Hexagon Socket） | Variable Angle Bone Screw （Hexagon Socket） | Screw Diameter | Screw Length |
| ACPS Ⅱ 4×23~30 | End holes:10° Degrees of convergence:6° | End holes:+16°/+4° Middle holes:±6° | φ4.0mm | 12~18mm |
| ACPS Ⅱ 6×37.5~50 | φ4.5mm | |||
| ACPS Ⅱ 8×52.5~70 |
